DDAL04
D and D Hardware
UL Listed, UL 10C Fire Rated 3 Hours, File No.:R40901
Stainless Steel 304
SSS, PSS, PVD, AB, AC ,MB
Silver,Black, Golden, Antique Brass, Antique Copper
Wooden Door, Metal Door
T/T, L/C, D/P, Western Union
Jiangmen /Guangzhou / Shenzhen , China
200,000/Month
| Quantity: | |
|---|---|
A UL 10C fire-rated mortise lock is compatible with both wood and metal fire-rated doors. However, to ensure proper functionality and compliance, you must first confirm that the lock's UL listing explicitly covers the specific door material you intend to use. Additionally, it's crucial to match the UL 10C 3-hour fire ratings between the lock and the door. Finally, strictly adhere to the manufacturer's installation guidelines tailored to the door type. For further information, please contact us.
Product Overview
Product name | Architectural Hardware Supplier UL Entry Function Commercial Fire Mortise Locks USA |
Product Model | DDAL04 |
Certification and Compliance | ANSI/BHMA A156.13-2005 Grade 1, UL 10C Fire Rated 3 Hours, File No.: R40901 |
| Color | Silver, Black, Golden, Antique Brass, Antique Copper |
Lockcase | Heavy Gauge Stainless Steel for Corrosion Resistance |
Deadbolt | Solid Casting SUS304, Project 1"（25.4mm） |
Latchbolt | Solid Casting SUS304, Project 3/4"（19mm）,Anti-Friction Two Pieces and Can be Reversible |
Auxiliary Latchbolt | Stainless steel |
Forend | Stainless steel Grade 304 |
Strike | Stainless steel Grade 304, Non-Handed |
Door Thickness | 45mm to 55mm As Standard |
Backset | 2-3/4" (70mm) |
Center to Center | 3-5/8" (92mm） |
Door Handing | Left Hand and Right Hand |
Packaging & Shipping
MOQ | 200PCS |
Package | 1pc /poly bag,white box / color inner box,Standard export Carton . |
Sample time | 5-7 working days |
Production lead time | 30-35 days normally |
Shipping Port | Jiangmen , China / Shenzhen , China |
Contact us
